CT Scan to 3-D Drawings

Project Overview

We were approached by a client to convert high-resolution CT scan data into detailed 3D CAD models for use in medical product development and biomechanical research. The objective was to reconstruct accurate geometries of internal anatomical structures and convert them into engineering-grade 3D files compatible with modelling, analysis, and manufacturing workflows. This project required a high degree of technical accuracy, clean geometry, and biological fidelity, and it played a critical role in developing patient-specific implants and surgical planning tools.

  • Share:
images

What We Delivered

• Conversion of DICOM Images to 3D STL Models
Using advanced segmentation tools and medical imaging software, we extracted bone and tissue structures from raw CT scan data.

• Surface Optimization & Mesh Refinement
Cleaned up STL meshes to eliminate noise and artefacts, ensuring smooth contours and manufactural geometry.

• Solid CAD Modelling
Converted STL into parametric CAD models (STEP, IGES, or native formats), suitable for 3D printing, CNC machining, or simulation.

• Custom Feature Integration
Added mounting holes, fitment slots, and support structures based on surgical or mechanical use cases.

• Multi-format Output
Delivered editable files in both organic mesh and solid-body formats — ready for FEA, CAM, or additive manufacturing.

Applications & Value

• Surgical planning and implant design
• Biomechanical simulation and analysis
• Custom prosthetics and orthotic systems
• Reverse engineering of anatomical models for device prototyping
• Med-tech training and diagnostic device R&D

Outcome

The project enabled our client to transform diagnostic imaging data into engineer-ready 3D models, dramatically reducing the development time of custom medical devices. This initiative highlights our cross-disciplinary capabilities in medical imaging, CAD modelling, and digital fabrication — bridging the gap between diagnostics and design.

Project Highlights

  • Project Type

    Medical Imaging to 3D Model Conversion

  • Status:

    Delivered

  • Project Summary

    We helped a med-tech client convert diagnostic CT scans into high-precision 3D CAD models, enabling faster development of custom implants, surgical tools, and anatomical prototypes. This end-to-end pipeline bridged imaging with manufacturable outputs for clinical and engineering teams.
